2.Display Resolution:1920*1080(or 4K)
3.Capacitive/IR touch screen
4.I/O: HDMI,VGA,USB
Since our inception, Shenzhen Innoda Technology Co., Ltd. has been engaged in the R&D of products to keep us ahead of other competitors in the industry. It is consistent with industry standards. Reflecting the latest industry trend and development, our 17 Inch 19 Inch 21.5 Inch Open Frame Touch Screen Monitor is designed to be attractive enough to catch people's attention. Moreover, it has some excellent characteristics, which makes it more value-added. In this competitive market, this LCD Monitors has the greatest appreciation space.
Warranty(Year): | 1-Year | Color: | Black |
Display Ratio: | 16:9 | Series: | For Business |
Aspect Ratio: | 16:9 | Screen Type: | LCD |
Pixel Pitch: | 0.276mm | Horizontal Viewing Angle: | 85° |
Built-in Speaker: | No | Vertical Viewing Angle: | 85° |
After-sales Service: | Call Center and on-line Technical Support, Return and Replacement | Products Status: | New |
Application: | Desktop | Response Time: | 3ms |
Brightness: | 300cd/m, 300 cd/m | Interface Type: | DVI, VGA, usb, LVDS EDP |
Contrast Ratio: | 500:1, 1200:1, 1200:1 | Widescreen: | Yes |
Panel Type: | IPS | Brand Name: | innoda |
Place of Origin: | Guangdong, China | Feature: | Touch Screen, Building in Camera |
Use: | Industrial | Product Name: | 17 Inch Open Frame Touch Screen Monitor For Industrial |
Backlight: | LED Backlight | Viewing Angle: | 85/85/85/85 |
Power Supply: | DC12V | Screen Size: | 17.3" Monitor |
Keyword: | Industrial Touch Lcd Monitor | Type: | LCD+Touch Screen Panel+frame |
Key words: | 17.3 Inch Led Monitor | Function: | Multifunctional |
Certification: | FCC, ce, RoHS |
LCD Panel Parameters | ||
Screen Size | 17.3 Inch LED Panel(7-43inch is supported) | |
Resolution | 1920(H)*(RGB)*1080(V) (or 4K) | |
Aspect Ratio | 16:9 | |
Brightness | 300cm/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Voltage | 12V DC input | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Aluminum alloy+ metal | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm (optional) |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) |
IO Interface(Optional) | ||
VGA | 1 x VGA | |
USB | 1 x USB | |
DVI | 1 x DVI |
