15inch plastic + metal case monitor front panel mounted display HD desktop monitor is designed in different styles and varied sizes. The long-term maintenance of strong market competitiveness is inseparable from the emphasis on talents and technology. By gathering the elites in the industry together,Shenzhen Innoda Technology Co., Ltd. aim to make full use of their wisdom and experience to develop and manufacture competitive products. Our great wish is to become a leading enterprise on a global scale.
| Warranty(Year): | 1-Year | Color: | Black |
| Display Ratio: | 4:3 | Series: | For Business |
| Aspect Ratio: | 4:3 | Screen Type: | LCD |
| Pixel Pitch: | 0.276mm | Horizontal Viewing Angle: | 85° |
| Built-in Speaker: | No | Vertical Viewing Angle: | 85° |
| After-sales Service: | Return and Replacement | Products Status: | New |
| Application: | Desktop | Response Time: | 3ms |
| Brightness: | 350cd/m, 550 cd/m | Interface Type: | DVI, VGA, usb |
| Contrast Ratio: | 500:1, 1200:1, 1200:1 | Widescreen: | Yes |
| Panel Type: | IPS | Brand Name: | innoda |
| Place of Origin: | Guangdong, China | Feature: | Touch Screen, Building in Camera, Touch Screen |
| Use: | Industrial | Product Name: | panel mounted display HD desktop monitor |
| Backlight: | IPS Lcd | Viewing Angle: | 85/85/85/85 |
| Power Supply: | DC12V | Screen Size: | 15" |
| Keyword: | HD touch screen monitor | Type: | LCD+Touch Screen Panel+frame |
| Certification: | ce, RoHS |
LCD Panel Parameters | ||
Screen Size | 15inch LED Panel | |
Resolution | 1024(H)*(RGB)*768(V) | |
Aspect Ratio | 4:3 | |
Brightness | 500cd/m2 | |
Touch type | Capacitive touch screen | |
View Angle | 85x85(H),85x85(V) | |
Contrast Ratio | 500:1 | |
Voltage | 12V DC input | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Aluminum alloy | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm | |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) | |||||
IO Interface(Optional) | ||
VGA | 1 x VGA | |
USB | 1 x USB | |
DVI | 1 x DVI | |
