Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Language
Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
With experienced, professional, and well-educated employees,Shenzhen Innoda Technology Co., Ltd. is efficient and excellent in developing products, one of which is OEM 15.6 inch ultra thin shell industrial control touchscreen monitor with VGA USB HD-MI interface. It has some unique features. Compared with other similar Guangdong, China products in the market, Shenzhen Innoda Technology Co., Ltd. it can be very stable and long-lasting when applied in the field(s) of LCD Monitors. Shenzhen Innoda Technology Co., Ltd. will always adhere to the business philosophy of honesty, innovation, integrity to run our business. We believe that with the combined efforts of all our employees, we have enough skills and capabilities to overcome all obstacles and difficulties to make some achievements in the future.
| Warranty(Year): | 1-Year | Color: | Black, Black Color |
| Display Ratio: | 16:9 | Series: | For Business |
| Aspect Ratio: | 16:9 | Screen Type: | LCD |
| Pixel Pitch: | 0.276mm | Horizontal Viewing Angle: | 85° |
| Built-in Speaker: | Yes | Vertical Viewing Angle: | 85° |
| After-sales Service: | Return and Replacement | Products Status: | New |
| Application: | Desktop | Response Time: | 3ms |
| Brightness: | 300cd/m, 300 cd/m | Interface Type: | VGA, usb |
| Contrast Ratio: | 500:1, 1200:1, 1200:1 | Widescreen: | Yes |
| Panel Type: | IPS | Brand Name: | innoda |
| Place of Origin: | Guangdong, China | Feature: | Touch Screen, Speaker, Building in Camera, USB Port |
| Certification: | ce, RoHS | Product Name: | ips Screen Assembly rugged monitor |
| Keyword: | Gaming Monitor | Size: | 15.6inch (16:9) |
| Backlight: | IPS LED | Interface: | HD+VGA+Audio |
LCD Panel Parameters | ||
Screen Size | 15.6 inch LED Panel | |
Resolution | 1920(H)*(RGB)*1080(V) | |
Aspect Ratio | 16:9 | |
Brightness | 500cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Voltage | 12 V DC input | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Aluminum Bezel / Stainless Steel | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm (optional) | |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) | |||||
IO Interface(Optional) | ||
VGA | 1 x VGA | |
USB | 1 x USB | |
DVI | 1 x DVI | |
