As a driven company,Shenzhen Innoda Technology Co., Ltd. has been developing products on our own on a regular basis, one of which is Shenzhen Innoda Technology Co., Ltd..It is the newest product and bound to bring benefits to customers. The key to small size screen display rugged 7inch usb powered open frame LCD monitor with metal case DC 12V competitiveness is innovation. Thanks to the multiple characteristics that have been tested by our QC inspectors,Shenzhen Innoda Technology Co., Ltd. has a wide application in different fields mainly including Open Frame Monitor.We hold a firm belief that the broad application of the product will drive the industry to develop and advance rapidly.
| Warranty(Year): | 1-Year | Color: | Black |
| Display Ratio: | 16:9 | Series: | For Business |
| Aspect Ratio: | 16:9 | Screen Type: | LCD |
| Pixel Pitch: | 0.276mm | Horizontal Viewing Angle: | 85° |
| Built-in Speaker: | No | Vertical Viewing Angle: | 85° |
| After-sales Service: | Return and Replacement | Products Status: | New |
| Application: | Desktop | Response Time: | 3ms |
| Brightness: | 300cd/m, 300 cd/m | Interface Type: | usb |
| Contrast Ratio: | 500:1, 1200:1, 1200:1 | Widescreen: | Yes |
| Panel Type: | IPS | Brand Name: | innoda |
| Place of Origin: | Guangdong, China | Feature: | Touch Screen, USB Port |
| Certification: | ce, RoHS | Product Name: | single usb port monitor |
| Keyword: | Computer Monitor | Backlight: | LED Backlight |
| Connector: | USB | Power Supply: | USB powered |
LCD Panel Parameters | ||
Screen Size | 7 inch LED Panel | |
Resolution | 1024(H)*(RGB)*768(V) | |
16:9Aspect Ratio | 16:9 | |
Brightness | 500cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Voltage | USB powered | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Aluminum Bezel / Stainless Steel | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm (optional) | |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) | |||||
IO Interface(Optional) | ||
USB | 1 x USB | |
