After long-term exploration and hard work, Shenzhen Innoda Technology Co., Ltd. have launched 10 inch ip66 stainless steel waterproof connector open frame monitor with USB VGA DVI HD interface that lead the industry. After years of special research and development, the products developed successfully break through the bottleneck of the pain points. Shenzhen Innoda Technology Co., Ltd. hope that we can respond more rapidly to changes in the industry with a deeper understanding of the market needs. We believe that we will stand out in the global market with our finest-quality products and unparalleled services.
| Warranty(Year): | 1-Year | Color: | Silver |
| Display Ratio: | 16:9 | Series: | For Business |
| Aspect Ratio: | 16:9 | Screen Type: | LCD |
| Pixel Pitch: | 0.276mm | Horizontal Viewing Angle: | 85° |
| Built-in Speaker: | No | Vertical Viewing Angle: | 85° |
| After-sales Service: | Return and Replacement | Products Status: | New |
| Application: | Desktop | Response Time: | 3ms |
| Brightness: | 350cd/m, 300 cd/m | Interface Type: | usb |
| Contrast Ratio: | 500:1, 1200:1, 1200:1 | Widescreen: | Yes |
| Panel Type: | IPS | Brand Name: | innoda |
| Place of Origin: | Guangdong, China | Feature: | Building in Camera, Building in Camera |
| Certification: | ce, RoHS | Product Name: | waterproof connector Industrial Touch Monitor |
| Backlight: | IPS LED | Viewing Angle: | 85/85/85/85 |
| Connector: | waterproof connector | Power Supply: | USB 5V |
| Size: | 10.1" |
LCD Panel Parameters | ||
Screen Size | 10.1inch LED Panel(7-21.5inch is supported) | |
Resolution | 1366(H)*(RGB)*768(V) | |
Aspect Ratio | 16:9 | |
Brightness | 500cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Voltage | 12V DC input | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Aluminum Bezel / Stainless Steel | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm (optional) | |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) | |||||
IO Interface(Optional) | ||
VGA | 1 x VGA | |
USB | 1 x USB | |
DVI | 1 x DVI | |
