Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Language
Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Concerning the industry development,Shenzhen Innoda Technology Co., Ltd. has been driven to develop new products to keep us competitive. We manufacture it in a variety of color and styles. In the future,Shenzhen Innoda Technology Co., Ltd. will continue to introduce outstanding talents and learn advanced technology, win the initiative in market competition, and clear road obstacles to achieve the goal of becoming a world-class enterprise.
| Warranty(Year): | 1-Year | Color: | Black |
| Display Ratio: | 4:3 | Series: | For Business |
| Aspect Ratio: | 4:3 | Screen Type: | LCD |
| Pixel Pitch: | 0.217mm | Horizontal Viewing Angle: | 85° |
| Built-in Speaker: | Yes | Vertical Viewing Angle: | 85° |
| After-sales Service: | Call Center and on-line Technical Support, Return and Replacement | Products Status: | New |
| Application: | Desktop, ATM.POS.Open Frame Machine ...etc | Response Time: | 3ms |
| Brightness: | 350cd/m, 300 cd/m | Interface Type: | VGA, usb, HDM-I |
| Contrast Ratio: | 500:1 | Widescreen: | Yes |
| Panel Type: | IPS | Brand Name: | innoda |
| Place of Origin: | Guangdong, China | Feature: | Touch Screen, Touch Screen |
| Use: | Industrial | Product Name: | Metal Housing Industrial Pcap Touch Monito |
| Size: | 15 17 19 Inch Optional | Backlight: | LED Backlight |
| Viewing Angle: | 85/85/85/85 | Inputs: | DC 12V |
| Keyword: | Touch Screen Display | Function: | Multifunctional |
| Certification: | ce, RoHS |
LCD Panel Parameters | ||
Screen Size | 15 inch LED Panel | |
Resolution | 1024(H)*768(V) | |
Aspect Ratio | 4:3 | |
Brightness | 350cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Voltage | 12 V DC input | |
Power Comsumption | < 20W | |
Operating Temperature | -20~60° C (-4~140° F) | |
Humidity | 5~95% @ 40° C, non-condensing | |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | |
Material | Metal / Aluminum Bezel / Stainless Steel | |
Color | Black/Silver/White | |
VESA Mounting | 75*75mm 100*100mm (optional) | |
Touchscreen Characteristics (Optional) | ||||||||||
Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch | |||||
Surface Hardness | 3H | 4H | 7H | 7H | 7H | |||||
Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times | |||||
Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) | |||||
IO Interface(Optional) | ||
VGA | 1 x VGA | |
USB | 1 x USB | |
HDMI | 1 x HDMI | |
