With the effort of excellent designers,Metal Case Embedded Industrial Sun Readable 1200 nits Outdoor LCD Monitor has unique style in its shape and appearance. Our range of LCD Monitors are made with the best ingredient. Shenzhen Innoda Technology Co., Ltd. will continue to adopt scientific and advanced marketing strategies to focus on market expansion, forming a complete sales network across the world. Moreover, we will pay more attention to the talents gathering, ensuring innovative and competitive wisdom is distilled for the long-term development of our company.
| Products Status: | Stock | Application: | embedded |
| Screen Size: | 10" | Response Time: | 5ms |
| Brightness: | 1000cd/m2 | Interface Type: | HDMI |
| Contrast Ratio: | ≤ 300:1 | Resolution: | 1024x600 |
| Widescreen: | Yes | Panel Type: | TFT |
| Brand Name: | INNODAPC | Place of Origin: | Guangdong, China |
| Pixel Pitch: | standard | Aspect Ratio: | 16:9 outdoor lcd monitor |
| Surface: | Flat Lcd Monitor | Working Temperature: | -20-70℃ |
| Backlight: | LED Backlight | Viewing Angle: | 70 /70 (L/R) |
| ODM/OEM: | Support | Material: | Metal case |
| Color: | Black White Silver...etc | Warranty: | 12 Months |
| Product Name: | Metal Case Embedded Industrial Outdoor LCD Monitor |
Metal Case Embedded Industrial Sun Readable 1200 nits Outdoor LCD Monitor
features
1. Sunlight readable outdoor lcd monitor
2.Industrial grade performance,7x24 working
3.Embedded mount type
4.Wide range operation temperature:-20-70℃
Note, 1000nits outdoor LCD Monitor can make customized design according to your demands.
More quantity more discount!
| LCD Panel Characteristics | |||||
| Screen Size | 10.1 inch LED Panel | ||||
| Resolution | 1024(H)*(RGB)*600(V) | ||||
| Aspect Ratio | 16:9 | ||||
| Brightness | 350cd/m2 | ||||
| View Angle | 80x80(H),80x80(V) | ||||
| Contrast Ratio | 500:1 | ||||
| Touchscreen Characteristics (Optional) | |||||
| Touchscreen Type | 4-Wire Resistive | 5-Wire Resistive | Projected Capacitive | Saw Touch | IR Touch |
| Surface Hardness | 3H | 4H | 7H | 7H | 7H |
| Working Life | 10 millions times | 10 millions times | 10 millions times | 10 millions times | 10 millions times |
| Transparency | 82%(±3%) | 88%(±3%) | 95%(±3%) | 95%(±3%) | 95%(±3%) |
| I/O Interface (Optional) | |||||
| VGA | 1 x VGA | ||||
| HDMI | 1 x HDMI | ||||
| USB | 1 x USB | ||||
| DVI | 1 x DVI | ||||
| Power Supply | |||||
| Voltage | Single 12 V DC power input | ||||
| Power Comsumption | < 20W | ||||
| Operating Environment (for reference, if you have special requirements on the temperature, pls inquiry our sales) | |||||
| Operating Temperature | -20~60° C (-4~140° F) | ||||
| Humidity | 5~95% @ 40° C, non-condensing | ||||
| Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis | ||||
| Enclosure | |||||
| Material | Aluminum Bezel / Stainless Steel | ||||
| Color | Black/Silver/White | ||||
| VESA Mounting | 75*75mm 100*100mm | ||||
| Product Dimensions | |||||
| Dimensions (L x W x H) | 337x238x38mm | ||||
| Net Weight | 2.5kg | ||||
| Packing Details | |||||
| Carton Size (L x W x H) | 402x301x101mm | ||||
| Gross Weight | 3.8kg | ||||
| Accessories | 1x2.6A Power Adapter with cable | ||||
1. Security packing method with bubble foam
2. Carton box / Wooden plate / Honeycomb carton
3. Standard one piece in a box, 2 boxes in a carton.
4. All Product will be checked 5 times before shipped.
5. For the shipping, you can choose DHL, Fedex, UPS or Use your forwarder, we will recommend economicaly way for your reference.
1.What is the MOQ?
---1pc sample is ok.
2. Could we have our own design?
----Yes, ODM/OEM is acceptable. Just tell us your request of the product,our R&D team will try to meet your needs.
3. Can i have my brand name(logo) on the product?
----No problem, just send us your logo design and pay the cost.
4.What about the after-service?
----1 year warranty. If product have any problems, pls contact us, and take some photos,videos. It's better for our engineer to find the reason and solve it.
5.How to ship it to my country?
---Usually the goods will be ship by DHL/Fedex/UPS/TNT....and so on. 3-5 working days arrival.
6.How long is the delivery time?
-----10-15working days upon receive the payment.
Innoda Technology Co.,Limited supplied embedded computer, inudstrail panel pc, touchscreen computer,different type monitors.Engineers have at least 6years experiance in all in one pc filed.
OEM/ODM is our strong points. Customized design is welcome.
