2.Memory: 4G/8G/16G DDR3
3.Storage:64/128/256G SSD
4.Resolution:1024*600
5.Touchtype:10points capacitive touch screen
6.Function: Wifi&BT(other function is optional)
7.I/O:1*RJ45,1*USB,1*HDMI
8.Power: DC 12V
Concerning the industry development,Shenzhen Innoda Technology Co., Ltd. has been driven to develop new products to keep us competitive. Innovation ability is the key to the core competitiveness of products. With a comprehensive understanding of the company management system, our employees can better realize their duties, which contributes to higher-efficiency manufacturing and more professional services. Our goal is to be a leading company in the global market.
Products Status: | Stock | Type: | Embedded Computer, Tablet PC |
Brand Name: | innoda | Place of Origin: | Guangdong, China |
Product name: | Fanless 10 Inch Embedded IP67 Waterproof Industrial AIO Panel Pc | CPU: | J1900 Quad Core |
Screen ratio: | 17:10 | Memory: | 2GB/4GB/8GB |
Storage: | 32G/64G/128G/256G SSD | Touch screen type: | Capacitive Screen |
Custom made: | Yes | Interface: | VGA USB |
Operating System: | Win7/8/10/linux | Certification: | FCC, ce, RoHS |
Computer Configurations | ||
CPU | Intel Celeron® Processor J1900,I3,I5,I7 | |
Memory | 4GB DDR3(Max. 8GB) | |
Storage | 64G SSD(320GB to 1TB, 32GB to 128GB SSD option) | |
Operation System | Linux/Ubuntu 14.04 LTS/Win 7/8/10 | |
Cooling | Fanless | |
I/O | 1*RJ45,1*USB,1*HDMI | |
Power Supply | DC 12V | |
Operating Temperature | -20~60° C (-4~140° F) |
LCD Panel Charateristics | ||
Screen Size | 10.1'' LCD/LED Panel(8-21inch is supported) | |
Touchscreen Type | Capacitive Touch(4/5Resistive/IR/SAW option) | |
Resoltuion | 1024(H)*(RGB)*600(V) | |
Brightness | 350cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 |
Other Function(Optional) | ||
GPIO Connector | 8-36V wide range voltage | |
CanBus | Webcam | |
Brightness Control in Manual and Auto | RF/NFC Reader |
Other Information | ||
Frame Material | Metal Case/Aluminum Alloy/Stainless Steel | |
Sheel Process Technic | Powder coated/Wire Drawing/CNC craft | |
Color | Default balck,also can choose white,silvery or other colour | |
VASA Mounting | 75*75 mm or 100*100 mm(optional) | |
Weight | 3KG |
