Thanks to the efforts of our employees including technicians and designers, Shenzhen Innoda Technology Co., Ltd. is able to introduce our .Industrial AIO 1000nits sunlight readable IP65 thin black alloy frame Intel J1900 CPU 7 to 21 inch panel pc to the public. Our range of Tablet PC are made with the best ingredient. Shenzhen Innoda Technology Co., Ltd. hope that we can respond more rapidly to changes in the industry with a deeper understanding of the market needs. We believe that we will stand out in the global market with our finest-quality products and unparalleled services.

Warranty(Year):1-YearScenarios:For Professional
Feature:Hardcharging interface:Proprietary
Drive Interface:usbAfter-sales Service:Return and Replacement
Products Status:NewProcessor Manufacture:Intel
Processor Type:Intel Celeron J1900Processor Main Frequency:1.8Ghz
Memory Capacity:4GBTouch Screen Type:Capacitive Screen
Display resolution:1024x768Operating System:Android 6.0
Weight:3KGPlace of Origin:Guangdong, China
Brand Name:INNODAPCModel Number:IND080PCS-434
Type:Tablet PC, Industrial Tablet, All in oneUse:Industrial
Certification:ce, RoHSProduct name:embedded industrial computer
Keywords:rugged tabletMaterial:Aluminum
Display:LCDWidescreen:No
Graphics Card Type:Integrated CardFan:No
Custom made:Yes

Recommend Products
Product Paramenters
Computer Configurations
CPU
Intel Celeron® Processor J1900 Quad Core 2.0GHz
Memory
2GB DDR3(Max. 8GB)
Storage
32G SSD(320GB to 1TB, 32GB to 128GB SSD option)
Operation System
Linux/Ubuntu 14.04 LTS/Win 7/8/10
Cooling
Fan / Fanless for optional
Power Supply
100V-240V,12V 7A AC Input,max 24W
Operating Temperature
-20~60° C (-4~140° F)
LCD Panel Charateristics
Screen Size
8'' LCD/LED Panel
Touchscreen Type
Capacitive Touch(4/5Resistive/IR/SAW option)
Resoltuion
1024(H)*(RGB)*600(V)
Aspect Ratio
4:3
Brightness
350cd/m2
View Angle
80x80(H),80x80(V)
Contrast Ratio
500:1
I/O Interface
USB
3xUSB2.0,1xUSB3.0
VGA
1xVGA
Serial Port(RS232)
1-2xRS232
LAN(RJ45)
1-2xRJ45
WIFI
Integrated
LVDS/EDP Output
Up to 1920*1080
Audio Output
Left and Right Chanel Output,8R/5W Loudspeaker
Other Function(Optional)
WIFI
3G/4G Module
GPIO Connector
8-36V wide range voltage
CanBus
Webcam
Brightness Control in Manual and Auto
RF/NFC Reader
Other Information
Frame Material
Metal Case/Aluminum Alloy/Stainless Steel
Sheel Process Technic
Powder coated/Wire Drawing/CNC craft
Color
Default balck,also can choose white,silvery or other colour
VASA Mounting
75*75 mm or 100*100 mm(optional)
Product Dimension(LxWxH)
TBD
Packing Dimension(LxWxH)
TBD
Weight
6KG
Details Images
Customizied Function
Main Products
All In One PC
CNC Technical PC
Industrial Monitor
Android Panel PC
Application
Product packaging
Company Profile
Innoda Technology Co.,Limited supplied embedded computer, inudstrail panel pc, touchscreen computer,different type
monitors.Engineers have at least 6years experiance in all in one pc filed.


OEM/ODM is our strong points. Customized design is welcome.
