Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Language
Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Our professional engineers have expertise in using technologies. It has a wide scope of range and is widely seen in the field(s) of Tablet PC. Now you can easily find the best suppliers to get the top of the line quality of 7" inch all in one Industrial computer touch screen panel PC with intel J1900 and get lower prices. Shenzhen Innoda Technology Co., Ltd. have always advocated the customer-centric business concept, aiming to provide customers with specialized, standardized, and diversified services. We focus on technology development and hope to make some innovations backed by strong technical strength.
| Warranty(Year): | 1-Year | Scenarios: | For Professional |
| Feature: | Shockproof | charging interface: | Proprietary |
| Drive Interface: | usb | After-sales Service: | Return and Replacement |
| Products Status: | New | Processor Manufacture: | Intel |
| Processor Type: | Intel Celeron | Processor Main Frequency: | 1.8Ghz |
| Memory Capacity: | ≥ 4GB | Touch Screen Type: | Capacitive Screen |
| Display resolution: | 800x600 | Operating System: | Windows 7, Win7/8/10/Linux/Ubuntu |
| Weight: | 3.5kg | Place of Origin: | Guangdong, China |
| Brand Name: | INNODA | Model Number: | IND070PCSIP1 |
| Type: | Tablet PC, Industrial Tablet | Use: | Industrial |
| Certification: | RoHS | Product name: | Industrial touch screen panel pc |
| CPU: | J1900 Quad Core | Memory: | 2GB |
| Storage: | 64G SSD | Display Type: | LCD |
| Touch screen type: | Capacitive touch screen | Screen ratio: | 16:9 |
| Frame material: | Metal case optional | Warranty: | 1Year |
Computer Configurations | ||
CPU | Intel Celeron® Processor J1900 Quad Core 2.0GHz | |
Memory | 4GB DDR3(Max. 8GB) | |
Storage | 128G SSD(320GB to 1TB, 32GB to 128GB SSD option) | |
Operation System | Linux/Ubuntu 14.04 LTS/Win 7/8/10 | |
Cooling | Fan / Fanless for optional | |
Power Supply | 100V-240V,12V 7A AC Input,max 24W | |
Operating Temperature | -20~60° C (-4~140° F) | |
LCD Panel Charateristics | ||
Screen Size | 7'' LCD/LED Panel | |
Touchscreen Type | Capacitive Touch(4/5Resistive/IR/SAW option) | |
Resoltuion | 800(H)*(RGB)*600(V) | |
Aspect Ratio | 16:9 | |
Brightness | 350cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
I/O Interface | ||
USB | 3xUSB2.0,1xUSB3.0 | |
VGA | 1xVGA | |
Serial Port(RS232) | 1-2xRS232 | |
LAN(RJ45) | 1-2xRJ45 | |
WIFI | Integrated | |
Other Function(Optional) | ||
WIFI | 3G/4G Module | |
GPIO Connector | 8-36V wide range voltage | |
CanBus | Webcam | |
Brightness Control in Manual and Auto | RF/NFC Reader | |
Other Information | ||
Frame Material | Metal Case/Aluminum Alloy/Stainless Steel | |
Sheel Process Technic | Powder coated/Wire Drawing/CNC craft | |
Color | Default balck,also can choose white,silvery or other colour | |
VASA Mounting | 75*75 mm or 100*100 mm(optional) | |
Product Dimension(LxWxH) | TBD | |
Packing Dimension(LxWxH) | TBD | |
Weight | 3.5KG | |
Contact Us
Please Contact Us
Welcome to be our partner! Let us help you to create a world-class leading industrial panel pc brand.
