Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.

Language
VR

Shenzhen Innoda Technology Co., Ltd. relying on years of market experience and strong scientific research technology, successfully developed Waterproof Tablet PC Ip67 Android Embedded Pc With 1000nits High Display. The research and development team is the core competence to Waterproof Tablet PC Ip67 Android Embedded Pc With 1000nits High Display. It enables us to become a leader in the 10''. In essence, product performance and its quality are largely decided by its raw materials. In terms of raw materials of Waterproof Tablet PC Ip67 Android Embedded Pc With 1000nits High Display, they have gone through plenty of tests on their chemical components and performance. In this way, the Shenzhen Innoda Technology Co., Ltd. quality is guaranteed from the source.

Warranty(Year):1-YearScenarios:For inudstrial/Boat
Feature:Waterproofcharging interface:no battery
Drive Interface:usbAfter-sales Service:Call Center and on-line Technical Support, Free spare parts, Return and Replacement, Repair, Others
Products Status:NewProcessor Manufacture:rockchip
Processor Type:RK3288Processor Main Frequency:1.8GHz
Memory Capacity:2gbTouch Screen Type:Capacitive Screen
Display resolution:1024x768Operating System:Android 6.0.1, Android6.0.1
Weight:5.5kgPlace of Origin:Guangdong, China
Brand Name:INNODAPCModel Number:IND104PC
Type:Tablet PC, Industrial TabletUse:Industrial
Flat Panel pc CPu:RK3288Touchscreen:10points capacitive Touchscreen
Environmet temperature:-20-70℃Waterproof Grade:IP65/IP67/IP68
LAN:1*RJ45 Gigabit LANLogo:Client logo acceptable
Warranty:12 MonthsColor:Black
Product Name:Tablet PC Ip67 Android Embedded Pc With 1000nits High DisplayCertification:ce, RoHS
Camera:Front Camera

Waterproof Tablet PC Ip67 Android Embedded Pc With 1000nits High Display



Features
Waterproof Protection Fully Sealed IP65(front,back,interface,power adapter)
All Functions are highly centralized USB/WIFI/BT4.1/eDp/SD card slot/LVDS/LAN
High Resolution Support 1080P/H.265(4K2K) Video Decoding and LVDS,eDP signal LCD screen
Loudspeaker 8R/5W
Verious Interface Support USB/COM/GPIO/ADC interface extension
Ip Protection Fully sealed IP65(Front,Back,Interface)
Application High-definition network player box, video advertising, frame advertising machine, interactive machine, security, industrial control and other intelligent control areas





Detailed Images



Product Description
Computer Configurations
CPU RK3288,Quad Cortex-A17+GPU Mail-T764,Up to 1.8G
Memory 2GB to Max. 4GB, DDR3
Built-in Storage EMMC8G/16G/32G,default 16G
Decoding The Resolution

Support 1080P/H.265(4K2K)

Operation System Android 6.0.1
Power Supply 90-264V AC input
Operating Temperature -20~70° C (-4~140° F)



LCD Panel Charateristics
Screen Size 21.5'' LCD/LED Panel
Touchscreen Type(optional) 4 wire/5wire Resistive touch/Capacitive Touch/SAW Touch/IR Touch
Resoltuion 1920(H)*(RGB)*1080(V)
Aspect Ratio 16:9
Brightness 350cd/m2
View Angle 80x80(H),80x80(V)
Contrast Ratio 1000:1



I/O Interface
USB 2 x USB2.0(Up to 6)
SD Card Slot Integrated
LAN(RJ45) 1xRJ45
LVDS/EDP Output Up to 1920*1200
Audio Output Left and Right Chanel Output,8R/5W Loudspeaker
Other Function(Optional)
Watch Dog RTC Real Time-Clock
Time Switch System Update
SD,USB automatic import screen parameter,boot logo



Other Information
Frame Material Aluminum Alloy/Stainless Steel
Sheel Process Technic Powder coated/Wire Drawing/CNC craft
Color Default balck,also can choose white,silvery or other colour
VASA Mounting 75*75 mm or 100*100 mm. Wall Mount/Desktop/Embedded/Rack-Mount
Product Dimension(LxWxH) 383.9x308.4x41.5mm
Packing Dimension(LxWxH) 440x370x190mm
Weight 6KG
Customer Comments

Customized Function

Packaging & Shipping

1. Security packing method with bubble foam

2. Carton box / Wooden plate / Honeycomb carton

3. Standard one piece in a box, 2 boxes in a carton.

4. All Product will be checked 5 times before shipped.

5. For the shipping, you can choose DHL, Fedex, UPS or Use your forwarder, we will recommend economicaly way for your reference.

Application

FAQ

1.What is the MOQ?

---1pc sample is ok.



2. Could we have our own design?

----Yes, ODM/OEM is acceptable. Just tell us your request of the product,our R&D team will try to meet your needs.



3. Can i have my brand name(logo) on the product?

----No problem, just send us your logo design and pay the cost.



4.What about the after-service?

----1 year warranty. If product have any problems, pls contact us, and take some photos,videos. It's better for our engineer to find the reason and solve it.



5.How to ship it to my country?

---Usually the goods will be ship by DHL/Fedex/UPS/TNT....and so on. 3-5 working days arrival.



6.How long is the delivery time?

-----10-15working days upon receive the payment.

Company Information

Shenzhen Innoda Technology Co.,Limited produce embedded computer, inudstrail panel pc, touchscreen computer,different type monitors and touch information kiosk. Engineers have at least 6 years experiance in all in one pc filed. OEM/ODM is our strong points. Customized design is welcome.
