Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.

Language
VR

In the fierce market competition, Shenzhen Innoda Technology Co., Ltd. has grown continuously. We invest in R&D to find better solutions in the Industrial Computer & Accessories industry. The Industrial Computer & Accessories product will supply to all over the world, such as Europe, America, Australia,Uganda , Oman ,Sri Lanka , Surabaya . Having analyzed the industry dynamics and researched the market development, we ensure our Shenzhen Innoda Technology Co., Ltd. has advantages in both its appearance and performance. It is designed to be of a unique structure and look, making it highly attractive to potential customers. In addition, the features of our Customized stainless steel case 15" j1900 waterproof 1024*768 industry rugged ip67 tablet pc makes it more valuable.

Products Status:StockType:Panel PC
Brand Name:INNODAPCModel Number:IND150PC-J19
Place of Origin:Guangdong, ChinaLCD Panel:15inch Industrial Standard LCD panel
CPU:J1900/2.0GhzRAM:2GB/4GB/8GB DDR3
ROM:32GB/64GB/128GB SSDOperating System:Linux/Ubuntu 14.04 LTS/Win 7/8/10
Environmet Temperature:-30-80℃Warranty:12 Months
Material:Stainless Steel / AluminumFan:Fanless
Product name:Customized stainless steel case 15" j1900 waterproof tablet pc

Customized stainless steel case 15" j1900 waterproof 1024*768 industry rugged ip67 tablet pc



 Follow link is our waterproof computer testing video,welcome to check it

https://youtu.be/tRaW1HTYbsw



Features

1.Waterproof design for industry application

2.Sensistive and fast response PCAP touch screen for optional

3.Muilttouch I/O ports with USB,LAN and COM Port.

4.Industrial fanless board,7x24hours of continuous work

5.Can do Customized design sunlight readable and waterproof function with 21000cd/m2-1500cd/m

Detailed Images



Noted, Sunlight Readable Computer Configuration can be customzied, so the price depends on the components and quantity.

Product Description
Computer Configurations
CPUIntel Celeron® Processor J1900 Dual Core 2.0GHz
Memory2GB to Max. 8GB, DDR3
Storage320GB to 1TB, 32GB to 128GB SSD
Operation System

Support Linux/Ubuntu 14.04 LTS/Windows 7/8/10

Default with Windows 7 OS Testing Version is preloaded.

CoolingFan / Fanless for optional
Power Supply100V-240V,12V 7A AC Input,max 24W power consumption
Operating Temperature-20~60° C (-4~140° F)



LCD Panel Charateristics
Screen Size17'' LCD/LED Panel
Touchscreen Type(optional)4 wire/5wire Resistive touch/Capacitive Touch/SAW Touch/IR Touch
Resoltuion1024(H)*(RGB)*768(V)
Aspect Ratio4:3
Brightness350cd/m2
View Angle80x80(H),80x80(V)
Contrast Ratio1000:1



I/O Interface
USB4xUSB2.0
VGA------
Serial Port(RS232)2xRS232
HDMI-------
LAN(RJ45)1xRJ45
Other Function(Optional)
WIFI3G Module
GPIO ConnectorPhoenix Connector 8-36V wide range power supply
BluetoothWebcam
Brightness Control in Manual and Auto Watchdog Timer



Other Information
Frame MaterialAluminum Alloy/Stainless Steel
Sheel Process TechnicPowder coated/Wire Drawing/CNC craft
ColorDefault balck,also can choose white,silvery or other colour
VASA Mounting75*75 mm or 100*100 mm
Product Dimension(LxWxH)360x288x57mm
Packing Dimension(LxWxH)460x390x160mm
Weight9KG
Customer Comments

Customized Function

Main Product

Packaging & Shipping

1. Security packing method with bubble foam

2. Carton box / Wooden plate / Honeycomb carton

3. Standard one piece in a box, 2 boxes in a carton.

4. All Product will be checked 5 times before shipped.

5. For the shipping, you can choose DHL, Fedex, UPS or Use your forwarder, we will recommend economicaly way for your reference.

Application

Company Information

Shenzhen Innoda Technology Co.,Limited produce embedded computer, inudstrail panel pc, touchscreen computer,different type monitors and touch information kiosk. Engineers have at least 6 years experiance in all in one pc filed. OEM/ODM is our strong points. Customized design is welcome.



Pls feel free to contact us as below methods, we will response to you in time.

Contact: Sunny

Tel: 0086-0755-29108731

Skype:  sunnytech24

Mobile/WatsApp: 0086 13554782291
