Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Language
Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Since its establishment, Shenzhen Innoda Technology Co., Ltd. has always strengthened exchanges and cooperation with outstanding domestic and foreign companies. After IP67 Waterproof PC Monitor 15inch 17inch 19inch 22inch industrial touch screen all in one pc with capacitive touchscreen launching into the market, we have gained a lot of support and praise. Most customers think that this kind of products are in line with their expectations in terms of appearance and performance. Our goal is to exceed the quality expectations of our customers. This commitment starts with the top-level management and extends through the entire enterprise. This can be achieved through innovation, technical excellence, and continuous improvement. In this way, Shenzhen Innoda Technology Co., Ltd. firmly believe that we will satisfy the growing needs of every customer.
| Products Status: | Stock | Type: | Panel PC |
| Brand Name: | INNODAPC | Model Number: | IND170PC |
| Place of Origin: | Guangdong, China | CPU: | J1900/2.0Ghz |
| RAM: | 2GB/4GB/8GB DDR3 | Voltage: | 12V DC |
| Operating System: | Linux/Ubuntu 14.04 LTS/Win 7/8/10 | Environmet Temperature: | -30-80℃ |
| Warranty: | 12 Months | Material: | Stainless Steel / Aluminum |
| Fan: | Fanless | Logo: | Your Logo is acceptable |
| Product name: | IP67 Waterproof Computer for Industry Application |
IP67 Waterproof PC Monitor 15inch 17inch 19inch 22inch industrial touch screen all in one pc with capacitive touchscreen
Follow link is our waterproof computer testing video,welcome to check it
https://youtu.be/tRaW1HTYbsw
Features
1.Waterproof design for industry application
2.Sensistive and fast response PCAP touch screen for optional
3.Muilttouch I/O ports with USB,LAN and COM Port.
4.Industrial fanless board,7x24hours of continuous work
5.Can do Customized design sunlight readable and waterproof function with 21000cd/m2-1500cd/m
Noted, Sunlight Readable Computer Configuration can be customzied, so the price depends on the components and quantity.
| Computer Configurations | |
| CPU | Intel Celeron® Processor J1900 Quad Core 2.0GHz |
| Memory | 2GB DDR3(Max. 8GB) |
| Storage | 32G SSD(320GB to 1TB, 32GB to 128GB SSD option) |
| Operation System | Linux/Ubuntu 14.04 LTS/Win 7/8/10 Default with Win 7 OS Testing Version is preloaded. |
| Cooling | Fan / Fanless for optional |
| Power Supply | 100V-240V,12V 7A AC Input,max 24W power consumption |
| Operating Temperature | -20~60° C (-4~140° F) |
| LCD Panel Charateristics | |
| Screen Size | 17'' LCD/LED Panel |
| Touchscreen Type | Capacitive Touch(4/5Resistive/IR/SAW option) |
| Resoltuion | 1280(H)*(RGB)*1024(V) |
| Aspect Ratio | 4:3 |
| Brightness | 350cd/m2 |
| View Angle | 80x80(H),80x80(V) |
| Contrast Ratio | 500:1 |
| I/O Interface | |
| USB | 3xUSB2.0,1xUSB3.0 |
| VGA | 1xVGA |
| Serial Port(RS232) | 1-2xRS232 |
| LAN(RJ45) | 1-2xRJ45 |
| Other Function(Optional) | |
| WIFI | 3G/4G Module |
| GPIO Connector | 8-36V wide range voltage |
| CanBus | Webcam |
| Brightness Control in Manual and Auto | RF/NFC Reader |
| Other Information | |
| Frame Material | Metal Case/Aluminum Alloy/Stainless Steel |
| Sheel Process Technic | Powder coated/Wire Drawing/CNC craft |
| Color | Default balck,also can choose white,silvery or other colour |
| VASA Mounting | 75*75 mm or 100*100 mm |
| Product Dimension(LxWxH) | 430x360x57mm |
| Packing Dimension(LxWxH) | 530x460x160mm |
| Weight | 10KG |
1. Security packing method with bubble foam
2. Carton box / Wooden plate / Honeycomb carton
3. Standard one piece in a box, 2 boxes in a carton.
4. All Product will be checked 5 times before shipped.
5. For the shipping, you can choose DHL, Fedex, UPS or Use your forwarder, we will recommend economicaly way for your reference.
Shenzhen Innoda Technology Co.,Limited produce embedded computer, inudstrail panel pc, touchscreen computer,different type monitors and touch information kiosk. Engineers have at least 6 years experiance in all in one pc filed. OEM/ODM is our strong points. Customized design is welcome.
Pls feel free to contact us as below methods, we will response to you in time.
Contact: Sunny
Tel: 0086-0755-29108731
Skype: sunnytech24
Mobile/WatsApp: 0086 13554782291
