Since 2014. Innoda is a professional waterproof industrial panel PC and touch screen monitor manufacturers.
Having absorbed the best and the brightest to join us, Shenzhen Innoda Technology Co., Ltd. finds it easier and more efficient to develop products on a regular basis.7 Inch Wall Mount Industrial Android Touch Screen Tablet is the newest result combining all the efforts and wisdom of our employees. High-end technologies helps us ensure 7 Inch Wall Mount Industrial Android Touch Screen Tablet quality, improve manufacturing efficiency, and reduce manpower input. It has extensive uses in the field(s) of Tablet PC. Thanks to the multiple characteristics that have been tested by our QC inspectors,Shenzhen Innoda Technology Co., Ltd. has a wide application in different fields mainly including 7''.We hold a firm belief that the broad application of the product will drive the industry to develop and advance rapidly.
| Warranty(Year): | 1-Year | Scenarios: | For Professional |
| Feature: | Shockproof, 3G/WIFI/BT/GPS/FM | charging interface: | Proprietary |
| Drive Interface: | usb | After-sales Service: | Call Center and on-line Technical Support, Return and Replacement |
| Products Status: | New | Processor Manufacture: | ROCKCHIP |
| Processor Type: | Quad Core | Processor Main Frequency: | 1.8ghz |
| Memory Capacity: | 2gb | Touch Screen Type: | Capacitive Screen |
| Display resolution: | 1024x600 | Operating System: | Android 9.0 |
| Weight: | 6kg | Place of Origin: | Guangdong, China |
| Brand Name: | innoda | Model Number: | IND070APCCTS03 |
| Type: | Tablet PC, Industrial Tablet | Use: | Industrial |
| Product name: | 7 Inch Wall Mount Industrial Android Touch Screen Tablet | System: | Andriod 9.0 |
| CPU: | RK3288 | RAM: | 1GB/2GB |
| ROM: | 8GB/16GB | Certification: | CE ROHS, FCC, ce, RoHS |
| Application: | 7 Inch Wall Mount Industrial Android Touch Screen Tablet | Keywords: | Android Touch Screen Tablet |
| Function: | Android Embedded Tablet Pc |
Computer Configurations | ||
CPU | RK3288,Quad Cortex-A17+GPU Mail-T764,Up to 1.8G | |
Memory | 2GB to Max. 4GB, DDR3 | |
Built-in Storage | EMMC8G/16G/32G,default 8G | |
Operation System | Android9.0 | |
I/O Ports | 2*USB,1*HDMI,1*RJ45,1*TF Card Slot,1*Audio output | |
Function | Wifi&BT Integrated (optional) | |
Power Supply | DC 12V | |
Operating Temperature | -20~70° C (-4~140° F) | |
LCD Panel Charateristics | ||
Screen Size | 7'' LCD/LED Panel | |
Touchscreen Type(optional) | 4 wire/5wire Resistive touch/Capacitive Touch/SAW Touch/IR Touch | |
Resoltuion | 1024(H)*(RGB)*600(V) | |
Aspect Ratio | 16:9 | |
Brightness | 350cd/m2 | |
View Angle | 80x80(H),80x80(V) | |
Contrast Ratio | 500:1 | |
Other Function(Optional) | ||
Watch Dog | RTC Real Time-Clock | |
Time Switch | System Update | |
Automatic import screen parameter,boot logo | NFC/RFID Reader | |
Other Information | ||
Frame Material | Aluminum Alloy/Stainless Steel/Metal | |
Sheel Process Technic | Powder coated/Wire Drawing/CNC craft | |
Color | Default balck,also can choose white,silvery or other colour | |
VASA Mounting | 75*75 / 100*100 mm. Wall Mount/Desktop/Embedded/Rack-Mount(optional) | |
Weight | 2.5KG | |
